ماسفت IRLML6401TRPBF
Detail
IRLML6401TRPBF
Part Number .
2897
Lion Part .
Datasheet .
Infineon Technologies Manufacture .
ماسفت 12 ولت 4.3 آمپر نوع P با پکیج SOT-23
P-CH MOS 12V 4.3A SOT-23
مشخصات ماسفت IRLML6401TRPBF
ماسفت IRLML6401TRPBF
Part Number .
1
Number of Channels .
Enhancement
Channel Mode .
-55C
Minimum Operating Temperature .
+150C
Maximum Operating Temperature .
Reel
Packaging .
±8V
Vgs - Gate - Source Voltage .
SMD/SMT
Mounting Style .
P-Channel
Transistor Polarity .
-12V
Vds - Drain - Source Breakdown Voltage .
-400mV
Vgs th - Gate - Source Threshold Voltage .
-4.3A
Id - Continuous Drain Current .
Single
Configuration .
10nC
Qg - Gate Charge .
1.3W
Pd - Power Dissipation .
50mΩ
Rds On - Drain - Source Resistance .
SOT-23-3
Package-Case .
