آپ امپ LM2904P
Detail
LM2904P
Part Number .
429
Lion Part .
Datasheet .
Texas Instruments Manufacture .
تقویت کننده عملیاتی 2 کاناله با پکیج PDIP-8
Dual Operational Amplifiers PDIP-8
مشخصات آپ امپ LM2904P
آپ امپ LM2904P
Part Number .
No Shutdown
Shutdown .
2
Number of Channels .
-40C
Minimum Operating Temperature .
+125C
Maximum Operating Temperature .
Tube
Packaging .
300mV/us
SR - Slew Rate .
Through Hole
Mounting Style .
65dB to 80dB
CMRR - Common Mode Rejection Ratio .
700KHz
GBP - Gain Bandwidth Product .
30mA
Output Current per Channel .
3V
Supply Voltage - Min .
3mV
Vos - Input Offset Voltage .
26V
Supply Voltage - Max .
250nA
Ib - Input Bias Current .
350uA
Operating Supply Current .
DIP-8
Package-Case .
