ماسفت IRFZ24N
Detail
IRFZ24N
Part Number .
3281
Lion Part .
Datasheet .
Infineon Technologies Manufacture .
ماسفت 55 ولت 17 آمپر نوع N با پکیج TO-220-3
N-CH MOS 55V 17A TO-220-3
معرفی
ماسفت منفی 55 ولت 17 آمپر پکیج TO-220
مشخصات ماسفت IRFZ24N
ماسفت IRFZ24N
Part Number .
1
Number of Channels .
Enhancement
Channel Mode .
+175C
Maximum Operating Temperature .
N-Channel
Transistor Polarity .
-55C
Minimum Operating Temperature .
Tube
Packaging .
Through Hole
Mounting Style .
±20V
Vgs - Gate - Source Voltage .
55V
Vds - Drain - Source Breakdown Voltage .
Single
Configuration .
2V
Vgs th - Gate - Source Threshold Voltage .
20nC
Qg - Gate Charge .
45W
Pd - Power Dissipation .
17A
Id - Continuous Drain Current .
70mΩ
Rds On - Drain - Source Resistance .
TO-220-3
Package-Case .
