ماسفت IRF7105TRPBF
Detail
IRF7105TRPBF
Part Number .
3313
Lion Part .
Datasheet .
Infineon Technologies Manufacture .
ماسفت جفت 25 ولت 3.5 و 2.3 آمپر نوع N و P با پکیج SO-8
DUAL N/P-CH MOS 25V 3.5/2.3A SO-8
مشخصات ماسفت IRF7105TRPBF
ماسفت IRF7105TRPBF
Part Number .
Enhancement
Channel Mode .
2
Number of Channels .
-55C
Minimum Operating Temperature .
N-Channel, P-Channel
Transistor Polarity .
+150C
Maximum Operating Temperature .
Reel
Packaging .
SMD/SMT
Mounting Style .
±20V
Vgs - Gate - Source Voltage .
25V, -25V
Vds - Drain - Source Breakdown Voltage .
Dual
Configuration .
1V, -1V
Vgs th - Gate - Source Threshold Voltage .
9.4nC, 10nC
Qg - Gate Charge .
3.5A, -2.3A
Id - Continuous Drain Current .
2W
Pd - Power Dissipation .
83mΩ, 160mΩ
Rds On - Drain - Source Resistance .
SOIC-8
Package-Case .
