TOSHIBA
مشخصات ماسفت TK62N60W
ماسفت TK62N60W
Part Number .
1
Number of Channels .
Enhancement
Channel Mode .
N-Channel
Transistor Polarity .
-55C
Minimum Operating Temperature .
+150C
Maximum Operating Temperature .
Tube
Packaging .
Through Hole
Mounting Style .
±30V
Vgs - Gate - Source Voltage .
Single
Configuration .
600V
Vds - Drain - Source Breakdown Voltage .
2.7V
Vgs th - Gate - Source Threshold Voltage .
33mΩ
Rds On - Drain - Source Resistance .
61.8A
Id - Continuous Drain Current .
180nC
Qg - Gate Charge .
400W
Pd - Power Dissipation .
TO-247
Package-Case .
